FlexiCore Compact Series Linear LED High Bay – Selectable 200W / 185W / 155W, 277–480V High Voltage, 4000K / 5000K CCT, AUX Control Ready
Schools
Warehouses
Manufacturing
Retail Sectors
Healthcare
Commercial
AL-LHB-2FT/200/185/155-CCT
- Linear Highbay
- Selectable CCT
- Commercial Lighting
- A modern 2-foot linear high-bay fixture designed to brighten your life in a sleek form. Delivering 30000/28000/23500 lumens and operating on 120-277V is ideal for commercial and industrial environments.
- This smart unit offers selectable wattages (200W / 185W / 155W) and adjustable color temperatures (4000K / 5000K).
Wattage
Lumens Output
CCT
Wide input voltage:
Lighting controls
Dimensions
DLC
V-hook
Efficiency
Warranty
(200W / 185W / 155W)
30000/28000/23500
4000K/5000K
120-277V
3.5 mm AUX port
22.8*10.2*1.8
6.0 Premium listed
Chain mounting included
Long lifespan
5-year
Wattage
(200W / 185W / 155W)
Lumens Output
30000/28000/23500
CCT
4000K/5000K
Wide input voltage:
120-277V
Lighting controls
3.5 mm AUX port
Dimensions
22.8*10.2*1.8
DLC
6.0 Premium listed
V-hook
Chain mounting included
Selectable Wattage:
Lumens Output:
Selectable CCT:
Wide input voltage:
DLC 6.0:
DLC 6.0 Premium:
Compact, low-profile
V-hook & chain
Energy-efficient
5-year
135W / 115W / 100W
20500/17500/15000
4000K/5000K
20500/17500/15000
120-277
Controls 3.5 mm
linear design
mounting included
long lifespan
warranty
FEATURES
DETAILS
Wattage
(200W / 185W / 155W)
Lumens Output
30000/28000/23500
CCT
4000K/5000K
Wide input voltage:
Wide input voltage:
Lighting controls
3.5 mm AUX port
Dimensions
22.8*10.2*1.8
DLC
6.0 Premium listed
V-hook
Chain mounting included
Efficiency
Long lifespan
Warranty
5-year
+
Construction
The fixture features a very durable sheet metal stamped housing with a white finish for structural strength. It is equipped with a high-quality polycarbonate (PC) optical glare-control lens that ensures uniform, low glare.
+
Electrical
An input voltage range of 120–277 V is very suitable for various commercial and industrial applications. 6 kV surge protection safeguards against voltage spikes and power fluctuations. The unit maintains a power factor of ≥0.9 to ensure optimal energy performance.
+
Mounting
This model has suspended installation along with a V-hook and chain. Optional mounting options comprise aircraft cable suspension, pendant mount, and a surface mount to suit various installation requirements.
+
Optical
A 90° beam distribution lens produces a very focused, uniform illumination ideal for high-ceiling applications.
+
Dimming & Control
Equipped with 0-10 V dimming for adjustable light levels, and control strategies help to achieve energy-saving goals. A 3.5 mm AUX audio jack receptacle is helpful for easy sensor integration.
+
Environment
This fixture is UL rated for damp locations and operates reliably in temperatures ranging from -40°C (-40°F) to 50°C (122°F), making it suitable for demanding environments.
+
Certification
This product is backed by a 5-year limited warranty that gives you peace of mind.
+
Warranty
This product has a 5-year limited warranty for long-term performance.
AL-LHB-2FT/200/185/155-CCT
|
Catalog Number |
Size |
Input Voltage |
Wattage |
CCT |
Lumen Output |
Efficacy |
Lifespan |
|---|---|---|---|---|---|---|---|
|
40 |
3000/3500/4000/5000 |
6000 |
|||||
|
AL-LNS-B-4FT/40/34/26/21-CCT-EM |
4FT |
120-277 |
34 |
3000/3500/4000/5000 |
5100 |
150 |
50000 Hours |
|
26 |
3000/3500/4000/5000 |
3900 |
|||||
|
21 |
3000/3500/4000/5000 |
3215 |
CATALOG NUMBER
SIZE
INPUT VOLTAGE
WATTAGE
CCT
LUMEN OUTPUT
EFFICACY
LIFESPAN
| AL-LHB-2FT/200/185/155-CCT | 2FT | 120-277 | 200 | 4000/5000 | 30000 | 150 | 50000 Hours |
| 185 | 4000/5000 | 27750 | |||||
| 155 | 4000/5000 | 23250 |
